The L7 stands alone as the most unique subwoofer on the market, with a cone shape that is exclusively designed to produce more output.
| Thiele/Small Parameters |
| 41L784 T/S Parameters |
| 3D Print Files |
| 52GL78-Spacer-41L7.STL - 3D-printing of grille spacers |
| Rated Impedance [Ω] |
| 4 |
| Sensitivity [1W, 1m] |
| 82.4 |
| Frequency Response [Hz] |
| 28 - 100 |
| Recommended Amplifier Power (watts RMS) |
| 500 |
| Outer Frame Dimension [in, cm] |
| 8-13/16, 22.4 |
| Mounting Depth [in, cm] |
| 5-7/16, 13.8 |
| Mounting Cutout [in, cm] |
| 7-1/4, 18.4 |
Sealed Enclosure Specs |
| Minimum Sealed Volume ft3 (L) |
| .4 (11.33) |
| Maximum Sealed Volume ft3 (L) |
| .75 (21.24) |
Panel Dimensions for Minimum Sealed Enclosures using 3/4” (1.9cm) thick MDF |
| Box Volume [ft³, L] |
.4 (11.33) |
| Panel A [in, cm] |
| 11x11, 27.9x27.9 |
| Panel B [in, cm] |
| 11x7.75, 27.9x19.69 |
| Panel C [in, cm] |
| 9.5x7.75, 24.13x19.69 |
Vented Compact |
| Box Volume, ft³ (L) + port displacement |
| .66 (18.69) |
| Port Opening Size, in x in (cm x cm) |
| 1.5x9.5 (3.8x24) |
| Port Length, in (cm) |
| 19.25 (49) |
Vented SQ |
| Box Volume, ft³ (L) + port displacement |
| 1 (28.32) |
| Port Opening Size, in x in (cm x cm) |
| 2x9.5 (5.1x24) |
| Port Length, in (cm) |
| 21.25 (54) |
| Warranty |
| When purchased from an Authorized KICKER Dealer or kicker.com, KICKER warrants this product to be free from defects in material and workmanship under normal use for a period of THREE (3) YEARS from date of original purchase. - Complete warranty information here. |
THE NEW L7
The KICKER L7™ Subwoofer again reaches new heights in technology and design, capturing the imaginations of 2015 CES® Innovation Award judges and solidifying itself as the crown jewel among industry subwoofers. For more than a decade, KICKER’s square woofer earned numerous awards including several CES accolades, and the 2015 version once again makes distinctive improvements on its way to another honor.
